K101612 TN Needle Roller Bearing Radial Needle Roller and Cage Assemblies K101612TN Bearings

BearingsBearingOverview The needle roller and cage assembly is an independent bearing element. The each of needle roller is guided and caged accurately by the cage. It has the highest load carrying capacity and the high rigid design in the smallest structure and space. The wide distance between two guiding surfaces of cage ensures the accurate guide of needle roller and cage assembly.Needle roller and cage assembly is suitable for the place where the shaft and housing bore are acted as the raceway. Under the geographic accuracy shaft and housing bore raceway, the highest rotation precision can be obtained.The working clearance in bearing location is dependent on the tolerance of inner and outer raceways, needle roller difference and working temperature.ClassificationAs for Model K, K D radial needle and retainer assembly, this kind of bearing only has a group of radial needle and retainer assembly. With small outside diameter size, it is suitable for the parts, where the radial sizes are specially limited, used for bearing the radial load. Model K ZW, K ZWD radial needle and retainer assembly is the double row radial needle and retainer assembly.As for this kind of bearing, since it has not collar, the surface of journal and the surface of hole at the housing are directly acted as rolling surface with surface hardness HRC 60 and surface roughness Ra no more than 0.63 m.In order to satisfy the requirement of main machine, this kind of bearing can be made in split bearing, convenient for mounting. Model K D represents as the single row split bearing and Model K ZWD represents as double row split bearing.(1-1) K single-row radial needle roller and cage assembly(1-2) K...ZW double-row radial needle roller and cage assembly(1-3) K... D partial single-row radial needle roller and cage assembly(1-4) K...ZWD double-row radial needle roller and cage assemblyFeatures:Needle bearings are
